Size | - Approximately 4.5 inches tall x 10.7 inches wide x .55 inches thick (with Joy-Con™ 2 controllers attached).
- *The maximum thickness from the tip of the control sticks to the protruding parts of the ZL/ZR buttons is 1.2 inches.
|
Weight | - Approximately .88 lbs
(Approximately 1.18 lbs with Joy-Con 2 controllers attached)
|
Screen | - Capacitive touch screen
- 7.9-inch wide color gamut LCD screen
- 1920x1080 pixels
- HDR10 support
- VRR up to 120 Hz
|
CPU/GPU | - Custom processor made by NVIDIA.
|
Storage | - 256 GB (UFS)
- *A portion of the storage is reserved for use by the system.
|
Communication features | - Wireless LAN (Wi-Fi 6)
- Bluetooth
- In TV mode, Nintendo Switch 2 can be connected using the wired LAN port on the dock.
|
Video output | - Output via HDMI connector in TV mode
- Maximum of 3840x2160 (4K) resolution at 60 fps (TV mode)
- Supports 120 fps when 1920x1080/2560x1440 resolutions are selected
- Supports HDR10
- *Maximum 1920x1080 resolution in tabletop mode and handheld mode, following screen resolution.
|
Audio output | - Supports linear PCM output 5.1ch
- Output via HDMI connector in TV mode
- *Surround sound effect can be applied when outputting to headphones or to the built-in speaker (surround sound effect when outputting to the built-in speaker requires a system update).
|
Speakers | - Stereo. The independent enclosure structure provides natural, clear sound quality.
|
Microphone | - Built-in microphone (monaural)
- Noise cancellation, echo cancellation, and auto gain control provide a more comfortable voice chat experience.
|
Buttons | - POWER Button/Volume buttons
|
USB-C® connectors | - 2 USB-C® connectors
- The port on the bottom is used to charge the console and connect to the Nintendo Switch 2 dock. The port on the top is used to connect accessories and/or charge the console.
|
Audio jack | - 3.5mm 4-contact stereo mini-plug (CTIA standard)
- Please note: Nintendo cannot guarantee functionality with all products.
|
Game card slot | - Both Nintendo Switch 2 and Nintendo Switch game cards can be inserted.
|
microSD Express card slot | - Compatible with microSD Express cards only (up to 2 TB)
- *microSD memory cards that are not compatible with microSD Express can only be used to copy screenshots and videos from Nintendo Switch.
|
Sensors | - Accelerometer, gyroscope, and mouse sensor located in Joy-Con 2 controllers
- Brightness sensor located in console
|
Operating environment | - 41-95 degrees F / 20-80% humidity
|
Internal battery | - Lithium-ion battery/5220mAh
|
Battery life | - Approx. 2 – 6.5 hours
- *These are rough estimates. The battery life will depend on the games you play.
|
Charging time | - Approximately 3 hours
- *While the system is in Sleep mode.
|
